Yaesu G-1000DXC Rotator 220V2 cu conector, fără cablu
Descriere
Yaesu G-1000DXC Rotator 220V2 cu conector, cablu WO.
| Power Supply Voltage: | 117 VAC, 50-60 Hz |
| Power Supply Current Consumption: | 1.0 Amp |
| Rotor Voltage: | 11-24 VDC |
| Cable Conductors Required: | 6 |
| 360° Rotation Time (Non Loaded): | 100 ą10 sec |
| 0 | 40 ą 5 sec (Variable) |
| Rotation Range: | 450° ą 3° |
| Rotation Torque: | 43-79 Ft. Lbs. (600 to 1,100 kgf-cm) |
| Braking Torque: | 6000 kgf-cm |
| Maximum Vertical Load: | 440 Lbs. (200 kg) continuous |
| 1320 Lbs. (800 kg) momentary | |
| Mast Outside Diameter: | 1.5 to 2.5 inches (38 to 63 mm) |
| Braking Type: | Mechanical and Electrical stoppers |
| Antenna K Coefficient: | 230 or less |
| Wind Loading Area: (Pole Type) | 0.75 m2 |
| (Tower Type) | 2.2 m2 |
| Maximum Continuous Duty: | 3 minutes |
| Operating Temperature Range: | 0°C to +40°C (Controller) |
| -20°C to +40°C (Rotator) | |
| Rotator Dimension: | 7.5 inches diameter 12.5 inches high (186 x 300 mm) |
| Rotator Weight: | 7.7 Lbs. (3.6 kg) |
| Controller Dimension (WHD): | 200 x 130 x 193 mm |
| Controller Weight: | Approx. 2.8 kg |
| 0 | |
| Specifications are subject to change without notice or obligation. | |
