Descriere
The Telox BN500 is a hybrid, dual-mode transceiver that combines both DMR and Push-to-Talk over Cellular (PoC) technologies. It is an ideal choice for professionals who regularly communicate in a critical and challenging environment.
All in One Dual Mode
Telox BN500 masterfully fuses DMR and POC technologies, presenting a Dual Mode powerhouse that operates both simultaneously. With dual PTT buttons, switching between DMR and POC is effortless, elevating user experience to unparalleled versatility.
Highlights
All in One Dual Mode
Telox BN500 expertly combines DMR and POC technologies, offering a Dual Mode device that works simultaneously. With dual PTT buttons, switching between the two is easy, enhancing user experience greatly
Professional certification, trustworthy
IP68 certified for water, dust, and shock resistance. Withstands 1.5m drops, ensuring reliable communication in tough environments, enabling crucial discussions anywhere.
Powerful Battery Capacity
4000mAh large-capacity battery supports long battery life, providing customers with better usage experience.
HD Rear Camera for Clear Recording
Featuring a 13-megapixel main camera, Telox BN500 can capture high-quality, high-definition photos and videos. A higher pixel count means more detailed images.
Higher DMR Standard
Equipped with 2W DMR power, Telox BN500 can communicate at higher power in digital mode, offering longer range and better penetration, especially for professional users in wide or complex areas.
Refined and Forceful Sound
Our devices have 3-watt speakers for a great audio experience. Many sound quality optimisations ensure full and powerful team calls with clear sound.
Professional certification, trustworthy
IP68 certified for water, dust, and shock resistance, withstanding drops from 1.5m, ensuring reliable communication in tough environments, empowering your team for crucial discussions anywhere.
Higher DMR Standard
Equiped with 2W DMR power, Telox BN500 can communicate at higher power in digital mode, providing longer range and better penetration, especially for professional users who need to maintain clear communications over wide areas or in complex environments.
The Telox BN500 is a versatile, reliable communication device with hybrid technologies and rugged construction, ideal for outdoor work where you need a secure connection and ruggedness. It is also well suited for semi-professional media recording and is compatible with both DMR and PoC networks.
Inrico IRC380 Hybrid DMR-POC Radio Box Contents:
- Telox BN500 handheld transceiver
- USB cable
- 5V 2A travel charger
- 4000 mAh battery
- Belt clip
- Quick start guide
SPECIFICATIONS | |
Dimension | 137.2mm*59.4mm*28.5mm |
Weight | 311.5g |
Environmental | |
Dust And Water Intrusion | IP68 |
Drop Test | 1.5m |
Working Temperature | -20°C to + 60°C (-2°F to 140°F) |
Storage Temperature | -30°C to + 70°C (-40°F to 158°F ) |
Humidity | 0%RH~95%RH |
Interaction & Display | |
Display | Diagonal Dimension:3.5'' WVGA |
Resolution | 480*800 |
Touch Panel | support multiple touch,glove touch, wet fnger touch |
Buttons Front | Menu/Home/Back key, multi-function key P1/P2/P3 |
Top | Rotar knob/ Emergency Button |
Left | Power button/ DMR-PTT Button/PTT button/ Volume (Up / Down) |
Hardware | Specifications |
Processor | MTK6765, Octa-Core, 2.3GHz |
Memory | 4GB RAM +64GB ROM |
Camera Front | 5MP; Rear:13MP AF. Flashlight:one in rear (support torch mode) |
SD Card | Max 256GB |
Battery | 4000mAh |
Receive | Single |
Vibration | Support |
Voice Call | Support |
Sensor Platform | Standard:G-sensor/Light Sensor/Proximity-sensor/Geomagnetic |
Optional | Gyroscope |
Connectivity | Specifications |
Cellular Network | GSM:B2/B3/B5/B8 TD-SCDMA:B34/B39, WCDMA:B1/B2/B4/B5/B8, CDMA2000 1X/EVDO BC0, FDD-LTE:B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28a/B28b/B66, TDD-LTE:B34/B38/B39/B40/B41 |
VoLTE/ViLTE/VoWIFI | Support (Depends on MTK and the local operator) |
DMR | Frequency Range:UHF 400~470MHz VHF 136~174Mhz, TDMA:2 Time slots (repeater mode), Transmitting Power:2W, Channel Spacing:12.5 kHz (digital), External DMR antenna:Yes, Support Digital & Analog |
WiFi | 2.4G & 5G WIFI, Support wifi hotspot |
Bluetooth | 4.2 Support BLE |
Location | GPS+BDS |
NFC | YES |
Interface | Specifications |
Card Slot | Nano-SIM Card Slot * 2 |
Audio interace | M6 Radio Grade Audio Jack *1 |
USB | Type-C Standard:5V 2A |
Desktop Charger Interace | Desktop Charger Interace *1 |
Operating System | |
Standard | Android 13 |
Audio | Specifications |
Microphone | Dual MIC |
Noise-cancellation | Dedicated Noise-cancellation chip |
Speaker | φ40mm 3W Built-in Speaker |
