Descriere
Frequency | DC ~ 3000 MHz |
VSWR | LESS THAN 1.1 |
LOSS | LESS THAN 0,2 dB |
WITHSTAND POWER | 200W PEP |
VOLTAGE AT DISCHARGE START | DC 350V +- 15% |
DISCHARGE VOLTAGE OF SHOCK WAVE (1X40) | 1,000 V |
WITHSTAND CURRENT OF SHOCK WAVE (1X40) | 6,000 A |
REPETITIVE DISCHARGE OF SHOCK WAVE (1X40) | 500 A, 500 |
TIMES | DC 230+- 20% |
INSULATING RESISTANCE DC 100V | OVER 10,000 M |
SIZE | 78*41*21 mm |
WEIGHT | 113 g |
